spectrum analyzer hardware for OEM and System Integrators

ThinkRF provides high performance, cost-effective Real-Time Spectrum Analyzers for OEMs to integrate into their larger solution. Incorporate flexible, versatile and open technologies into your own monitoring, test and measurement, or research systems to provide specialized products across any industry.

10x more cost-effective

Reduce costs and improve margins with 10x lower cost per unit compared to similarly performing analyzers

10x more performance

Get the performance you need with 27 GHz frequency range and up to 100 MHz instantaneous bandwidth

10x more compact

Reduce size, weight and power requirements of larger solutions by integrating ThinkRF solutions

Expand your solution offerings with the R5500 Real-Time Spectrum Analyzer

Grow margins and provide better value to customers with patented Real-Time Spectrum Analyzer technologies from ThinkRF. 10x more cost-effective and compact than traditional analyzers, ThinkRF provides an unmatched cost-to-performance ratio that can expand the value of your offering to aerospace and defense customers, spectrum regulators, manufacturers or wireless service providers.

Give your customers the ability to:

  • analyze up 27 GHz frequency range, up to 160 MHz instantaneous bandwidth and a deep dynamic range at a fraction of the cost of other options.
  • network and remotely deploy the appliances for further freedom and connect them to a PC or directly to the network to get a complete, real-time view.

ThinkRF has worked with various OEMs to provide high performance real-time spectrum analyzer technologies.

electronic test and measurement solutions for OEM and System Integrators
rf spectrum analyzers for OEM and System Integrators
spectrum analyzer hardware for OEM and System Integrators

Product configuration for OEMs

The ThinkRF R5500 Real-Time Spectrum Analyzer is highly configurable and can be adapted to meet any OEMs’ need. The built in receiver and digitzer can be white labeled and integrated with any application by leveraging a rich set of APIs, protocols and programming environments. Or, couple the receiver with any third party digitizer for even more capabilities and a greater dynamic range.

The R5500 Real-Time Spectrum Analyzer supports:

  • SCPI and VITA VRT control and data protocols
  • Python™ and C++ APIs
  • PyRF Python Development Environment
  • ThinkRF S240 Real-Time Spectrum Analysis software application

Learn more about the R5500 Real-Time Spectrum Analyzer.

Learn more about the rich support for APIs and standard protocols.

Contact sales for more information about the configuration that’s best for you.
